C70600 90/10 Copper Nickel Alloy Sheet

Copper-nickel (also known as cupronickel) alloys offer excellent corrosion resistance to seawater and good fabricability. The addition of nickel to copper improves strength and corrosion resistance while allowing the alloy to remain ductile, other elements can be added to copper-nickel to increase strength, corrosion resistance, hardening, weldability and castability. The nickel-copper alloy has been widely used for r marine applications.

Online consultation

Product Introduction

Copper-nickel (also known as cupronickel) alloys offer excellent corrosion resistance to seawater and good fabricability. The addition of nickel to copper improves strength and corrosion resistance while allowing the alloy to remain ductile, other elements can be added to copper-nickel to increase strength, corrosion resistance, hardening, weldability and castability. The nickel-copper alloy has been widely used for r marine applications. C70600 often known as 90/10 copper-nickel, is the alloy with 90% copper and 10% nickel, has been widely used in the automotive, admiralty, shipping, offshore as well as power generation.

Wiho metals is a fully stocked and leading metal manufacturer, supplier, exporters, distributors. We stock the copper alloy mill-product in the forms of plate, tubing, bar and rod. The copper alloy products provide by us shall be fabricated from prime quality raw materials and is fully certifiable to industrial specifications like ASTM and ASME or other relevant standards. Wiho metals supply and stock a large inventory of alloy Copper C70600 (C706/CW352H/C7060T) plate/sheet in accordance with ASTM B122 used for offshore, seawater cooling and firewater applications. For more information on our extensive copper alloys inventory, please contact us or fill in the form below.

C70600 Equivalent Material

Type

ASTM

EN

BS

DIN

JIS

GB

90Cu-10Ni

C70600

CW352H

CN102

CuNi10Fe 1Mn

CuNi10Fe 1.6Mn

C7060T

B10(BFe30-1-1)

C70600 Chemical Composition

Cu

Fe

Ni+Co

Pb

Sn

Mn

Zn

88.600

1.0 – 1.5

9.0 – 11.0

≤0.05

≤0.03

0.5~1.0

≤0.3

C70600 Mechanical Property

Tensile strength, Mpa

Yield strength, Mpa

Elongation, %

414

393

10

C70600 Physical Properties

Density

8.94 gm/cm3 @ 20 C

Melting Point – Liquidus

1149 C

Electrical Conductivity

0.053 MegaSiemens/cm @ 20 C

Coefficient of Thermal Expansion

17.1 . 10-6 per oC (20-300 C)
