W75Cu25 Tungsten-Copper Alloy Bar

Tungsten Copper Electrodes are WIDELY used, mainly used in the manufacture of high voltage switch contacts, rocket nozzle throat liner, tail rudder and other high temperature parts, can also be used as electrical processing electrode, high temperature mold and other occasions requiring high conductivity and high temperature.

Online consultation

Product Introduction

Detail Information

Material:

Tungsten Copper Electrodes

Grade:

W75Cu25

Size:

Dia 3-50mm X L

Density:

14.5 G/cc

Hardness:

175 HB

Standard:

ASTM B702-93 2012

Packaging:

Exporting Plywood Cases

Application:

Welding

High Light:

Resistance Welding Tungsten Copper Alloy Electrodes,

W75Cu25 Tungsten Copper Alloy Electrodes,

175 HB Tungsten Copper Alloy Electrodes

Tungsten Copper Electrodes For Resistance Welding W75Cu25

Tungsten Copper Electrodes are WIDELY used, mainly used in the manufacture of high voltage switch contacts, rocket nozzle throat liner, tail rudder and other high temperature parts, can also be used as electrical processing electrode, high temperature mold and other occasions requiring high conductivity and high temperature.

Specifications of Tungsten Copper Electrodes

Code No.

Chemical Composition %

Mechanical properties

CU

Impurity

W

Density (g/cm3 )

Hardness HB

RES( cm)

Conductivity IACS/ %

TRS/ Mpa

CuW(50)

50±2.0

0.5

Balance

11.85

115

3.2

54

CuW(55)

45± 2.0

0.5

Balance

12.30

125

3.5

49

CuW(60)

40±2.0

0.5

Balance

12.75

140

3.7

47

CuW(65)

35±2.0

0.5

Balance

13.30

155

3.9

44

CuW(70)

30±2.0

0.5

Balance

13.80

175

4.1

42

790

CuW(75)

25±2.0

0.5

Balance

14.50

195

4.5

38

885

CuW(80)

20±2.0

0.5

Balance

15.15

220

5.0

34

980

CuW(85)

15±2.0

0.5

Balance

15.90

240

5.7

30

1080

CuW(90)

10±2.0

0.5

Balance

16.75

260

6.5

27

1160

Production process of Tungsten Copper Electrodes

Tungsten copper is an alloy of tungsten and copper. Tungsten copper alloy is composed of fine tungsten and copper powder, which is refined through isostatic pressing, tungsten skeleton high temperature sintering, copper dissolution and other first-class immersion sintering processes.

Applications of Tungsten Copper Electrodes

Resistance welding electrode: tungsten-copper alloy integrates the advantages of tungsten and copper, high temperature resistance, arc ablation resistance, high strength, specific weight, good electrical conductivity, good thermal conductivity, easy to machining, and has the characteristics of sweating and cooling. Because tungsten copper alloy has the characteristics of high hardness, high melting point and anti-adhesion of tungsten, it is often used to make convex welding and butt welding electrodes with certain wear resistance and high temperature resistance.

Edm electrode: for tungsten steel, high temperature resistant superhard alloy mold needs electric corrosion, the ordinary electrode loss is large, slow. The characteristics of high corrosion speed, low loss rate, precise electrode shape and excellent machining performance of tungsten-copper alloy can greatly improve the accuracy of the workpiece.
