Product
CuNi2Be—C17510 (CDA 1751) Nickel Beryllium Copper is the mirror image of alloys C17500 in terms of its properties & Characteristics. C17510 is also primarily utilized in the industry applications that require the most highly thermal or electrical conductivity, which features a Nickel alloying addition (1.40-2.20%). C17510 also offers good strength and hardness characteristics coupled with conductivity in the range of 45-60 percent of copper with ultimate tensile and hardness properties approaching 140 ksi and RB 100 respectively.
Online consultation
Product Introduction
Element | |||||||
Cu(1,2) | Fe | Ni | Al | Be | Co | Si | |
(1) Cu + Sum of Named Elements 99.5% min.(2) Cu value includes Ag. | |||||||
Min (%) | 1.4 | 0.2 | |||||
Max (%) | Rem | 0.10 | 2.2 | 0.20 | 0.6 | 0.3 | 0.20 |
Physical Properties
Melting Point - Liquidus°F | 1955 |
Melting Point - Solidus°F | 1885 |
Density lb/cu in. at 68°F | 0.317 |
Specific Gravity | 8.77 |
Electrical Conductivity% IACS at 68°F | 48(1) |
Electrical Conductivity% IACS at 68°F | 45(2) |
Thermal ConductivityBtu/ sq ft/ ft hr/ °F at 68°F | 120 |
Coefficient of Thermal Expansion 68-39210⁻⁶ per °F (68 – 392°F) | 9.8 |
Specific Heat CapacityBtu/ lb /°F at 68°F | 0.1 |
Modulus of Elasticity in Tensionksi | 19200 |
Modulus of Rigidityksi | 7500 |
(1) Cold worked and precipitation hardened condition. HT Temper
(2) AT Temper
Applications
The applications of UNS C17510 copper alloys include:
Plastic molds
Bearings
Electrical/electronic connectors
Precision screw machined parts
Corrosion-resistant components
Current-carrying springs
Welding electrodes
Strip | ASTM B 534-07, B 888 | JIS H 3130 |
Sheet | ASTM B 534-07, B 888 | JIS H 3130 |
Rod | ASTM B 441-04, ASTM B 534-07 | |
Tube | ASTM B 937, ASTM B 944 | |
Profile | ASTM B 870-08 | |
Forgings | ASTM B 870-08, ASTM B 938 |
