Copper and nickel are extremely valuable, commodity traded metals, and as an alloy, they form a rather formidable material. The chemical composition of DIN 2.0882 Cold Rolled Plates consists of a large portion of copper which stands at 70%. Copper is followed by about 30% nickel, which is the second largest alloyant in the material.
Online consultation
Product Introduction
Copper and nickel are extremely valuable, commodity traded metals, and as an alloy, they form a rather formidable material. The chemical composition of DIN 2.0882 Cold Rolled Plates consists of a large portion of copper which stands at 70%. Copper is followed by about 30% nickel, which is the second largest alloyant in the material.
The alloy for Astm B122 Cuni 70/30 Polished Plates is produced with additions of two more elements, that is iron and manganese. The elemental composition of the Cupro Nickel 70 / 30 Coils makes the material moderately higher in terms of resistance to corrosion and resistance to erosion. By adding iron and manganese in the alloy of Cupro Nickel 70/30 Strip the alloy exhibits a slight improvement in tensile strength level as opposed to copper nickel 90/10. Thus the chemical composition of the 70/30 Copper Nickel Sheet makes it well suited for use in more demanding and aggressive applications. In particular, its corrosion resistance property of the Copper Nickel 70/30 Sheet & Plate distinctly witnesses a rise when it has been used in high-velocity waters, where the speed turns up to 4.5m/s or when the alloy is used in polluted seawater.
View ASME SB 122 Cuni 70/30 Shim Sheets price per meter ex. Mumbai
Table of Content
Copper Nickel 70/30 Sheet Material Specification
Most Commonly Used UNS C71500 CuNi 70/30 Plate Types
Size Chart Of Cu-Ni 70/30 Strip
Cupro Nickel 70/30 Coils Thickness
ASTM B122 Cuni 70/30 Polished Plates Width
DIN 2.0882 Cold Rolled Plates Chemical Composition Standard
70/30 Copper Nickel Sheet Mechanical Behaviour
Cupro Nickel 70/30 Hot Rolled Plates Equivalent Grades
Cupro Nickel 70/30 Foil Stock
Copper Nickel 70/30 Sheet Material Specification
Check dimensions and specification of Cupro Nickel 70/30 Coils, Werkstoff No 2.0882 Cold Rolled Plates
End Product | Specification |
Plate | ASTM B122, MILITARY MIL-C-15726, SAE J461, J463 |
Plate, Clad | ASTM B432 |
Plate | ASME SB171, ASTM B171, SAE J463, J461 |
Sheet | ASTM B122, MILITARY MIL-C-15726, SAE J463, J461 |
Strip | ASTM B122, MILITARY MIL-C-15726, SAE J461, J463 |
Specifications | ASTM / ASME SB122 |
Standard | GB/T5231-2001, GB/T1527-2006, JISH3100-2006, JISH3250-2006, JISH3300-2006, ASTMB152M-06, ASTMB187, ASTMB75M-02, ASTMB42-02, etc. |
Size | 1000 mm x 2000 mm, 1220 mm x 2440 mm, 1500 mm x 3000 mm, 2000 mm x 2000 mm, 2000 mm x 4000 mm |
Thickness | 0.1mm to 12 mm Thk |
Length Cut to Size | 10mm~12000mm, or as required. |
Form | Cuni 70/30 Sheet, Coil, Plate, Foils, Rolls, Plain Shim Sheet, Strip, Flats, Blank (Circle), Ring (Flange), Pata, Patti |
Finish | Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated) |
Hardness | Soft, Hard, Quarter Hard, Half Hard, Spring Hard etc. |
Surface | Mill, polished, bright, oiled, hair line, brush, mirror, sand blast, or as required. |
ASTM | ASME | Military | |
Copper Nickel 70/30 Sheet | ASTM B122 | ASME SB-122 | MIL-C-15726 |
70/30 Cu-ni Plate | ASTM B122 | ASME SB-122 | MIL-C-15726 |
70/30 Cupro Nickel Coil | ASTM B122 | ASME SB-122 | MIL-C-15726 |
Copper Nickel UNS C70600 Strip | ASTM B122 | ASME SB-122 | MIL-C-15726 |
Size Chart Of Cu-Ni 70/30 Strip
Many size range of 70/30 Copper Nickel Sheet and Cupro Nickel C71500 Coils
Thickness In. | Size In. | Lbs. Per Sq. Ft. | Lbs. Per Plate |
1/4 | 48 x 144 | 11.6 | 558 |
3/8 | 48 x 144 | 17.4 | 836 |
1/2 | 48 x 144 | 23.3 | 1116 |
3/4 | 48 x 144 | 34.9 | 1674 |
1 | 48 x 144 | 46.5 | 2232 |
1 1/4 | 48 x 144 | 58.1 | 2790 |
1 1/2 | 48 x 144 | 69.8 | 3348 |
2 | 48 x 144 | 93.0 | 4464 |
2 1/2 | 48 x 144 | 116.3 | 5582 |
3 | 48 x 144 | 139.5 | 6696 |
3 1/2 | 48 x 144 | 162.7 | 7914 |
4 | 48 x 144 | 186.0 | 8930 |
5 | 24 x 96 | 233.0 | 3721 |
Min. Gauge | 0.0002" | 0.005mm | |
Max. Gauge | 0.006" | 0.150mm | For thicker gauges see Copper-Nickel Strip |
Min. Width | 0.032" | 0.8mm | For narrower widths see Copper-Nickel Wire |
Max. Width | 48.00" | 1,220mm |
Grade | Cu | Mn | Pb | Ni | Fe | Zn |
Cupro Nickel 70/30 | 65 min | 1.0 max | 0.05 max | 29-33 max | 0.4-1.0 max | 1 max |
Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
0.323 lb/in3 at 68 F | 2260 F | 50000 psi | 20000 psi | 30 % |
STANDARD | WERKSTOFF NR. | UNS |
Cupro Nickel 70/30 | 2.0882 | C71500 |
Copper Nickel WERKSTOFF NR. 2.0882 Shim Sheet | 70/30 Cu-ni Hot Rolled Plates |
70/30 Cu-ni Polished Plates | Cu-ni 70/30 Cold Rolled Plates |
Copper Nickel UNS C71500 Polished Plates | Cupro Nickel UNS C71500 Strips |
Copper Nickel WERKSTOFF NR. 2.0882 Hot Rolled Plates | ASTM / ASME SB122 Cupro Nickel 70/30 Cold Rolled Plates |
ASTM / ASME SB122 Cupro Nickel 70/30 Polished Plates | 70/30 Copper Nickel Hot Rolled Plates |
ASME SB122 Cupro Nickel 70/30 Strips | Copper Nickel WERKSTOFF NR. 2.0882 Cold Rolled Plates |
70/30 Cu-ni Coils | Cu-ni 70/30 Strips |
ASTM / ASME SB122 Cu-ni 70/30 Shim Sheet | 70/30 Cupro Nickel Polished Plates |
